Welcome: Chuzhou kexin Machinery Technology Co., LTD
Language: Chinese ∷  English

Internal biliary mold

  • Blister forming mold
Blister forming mold

Blister forming mold

  • Product description: Blister forming mold
  • INQUIRY

Blister forming mold

Working environment: temperature 00C~450C,relative humidity is not more than 90%.

Cylinder working pressure(bleed pressure) of core-pulling mechanism:0.5MPa~0.7MPa

Vacuum pressure:-0.09Mpa-0.1Mpa

Water cycle heating system: water temperature:900C~1000C,pressure≥0.05MPa

Mold working temperature:800C~900C

The diameter of the vacuum hole is generally Φ0.5mm-Φ0.8mm

Distribution of vacuum holes:The vacuum hole spacing is 30mm-50mm

Surface roughness requirements for mold forming:Ra≤0.8mm

Mold material:Cast aluminium alloy ZL401

The mold wall thickness:≥15mm
